Cement Compression Machine

The CANTROL Semi-Automatic Cement Compression Testing Machines allow less experienced operators to perform the tests. Once the machine has been switched on and the specimen is positioned and centered by the help of centering apparatus. The only required operations are; Setting test parameters, including pace rate (only required when the specimen type is changed.) Choosing the compression, Pressing the START button on the control unit. The machine automatically starts the rapid approach; switches the test speed after 1% of the load capacity of the machine and stops once the specimen failure. Automatically saves the test parameters and test results. The heavy duty steel stand and two steel spacers are included.
Model 2223010 2223020
Description Semi-Automatic Cement Compression Machine Semi-Automatic Cement Compression Machine
Capacity 600 kN 600 kN
Resolution 1 kN 1 kN
Power Supply 110 V,60 Hz., 0.75 KW,1 Ph 220 V, 50 Hz., 0.75 KW,1 PH
Stroke Limit 50 mm 50 mm
Piston Guide PTFE BRONZE PTFE BRONZE
Display 7» digital touch screen 7» digital touch screen
Calibration Method Software Software
Oil Capacity 25 Lit 25 Lit

Additional information

Description

Semi-Automatic Cement Compression Machine

Model

2223010, 2223020

Capacity

600 kN

Resolution

1 kN

Power Supply

110 V,60 Hz., 0.75 KW,1 Ph, 220 V, 50 Hz., 0.75 KW,1 PH

Stroke Limit

50 mm

Piston Guide

PTFE BRONZE

Display

7» digital touch screen

Calibration Method

Software

Oil Capacity

25 Lit

Included Items:

No data was found

Accessories:

No data was found
No data was found
No data was found
