In modern pavement engineering, the accuracy of stability and flow measurements is paramount. The Digital Marshall Testing Machine by CANTROL offers a sophisticated, bench-mounted solution for labs requiring precise bituminous mixture analysis. Designed with a rugged two-column stainless steel frame and an adjustable cross-beam, this compression system provides the structural rigidity necessary for high-capacity testing up to 50kN.
A standout feature of this Digital Marshall Testing Machine is its high-resolution 50kN load cell. With a 20N resolution, the stability tester captures minute details during the specimen breaking process. Technicians can monitor these metrics in real-time via the integrated 4-inch full-color touchscreen indicator. This smart interface streamlines the workflow, allowing for rapid adjustments and clear data visualization, which is essential for busy laboratory environments.
This specialized equipment operates at a consistent load rate of 50mm/min, ensuring full adherence to international protocols. While the breaking heads are ordered separately, the core Digital Marshall Testing Machine is built to support a wide array of asphalt specimens. Every unit is manufactured to last, featuring stainless steel components and a compact footprint that fits easily on standard laboratory workbenches.
Accuracy is nothing without compliance. This system is engineered to meet the strict requirements of ASTM D1559, D5581, and D6927, as well as AASHTO T245 and EN 12697-10. By maintaining these rigorous standards, the Digital Marshall Testing Machine ensures that your results are recognized and respected by regulatory bodies and engineering firms globally. From the 0.01mm dial gauge resolution to the high-torque motor, every component is optimized for professional-grade asphalt pavement assessment.
Key Technical Advantages:
Automated Precision: Integrated 50kN stainless steel load cell and a 10mm dial gauge (0.01mm resolution) for accurate stability and flow measurements.
Smart Interface: Equipped with a user-friendly 4-inch full-color touchscreen for real-time monitoring and control.
Rugged Design: Compact, bench-mounted frame with high-durability stainless steel columns and a 50mm/min constant load rate.
Versatile Application: Ideal for testing 4-inch and 6-inch specimens (breaking heads sold separately).
Global Compliance: Fully conforms to ASTM D1559, D5581, D6927, AASHTO T245, and EN 12697-10 standards.
| Description | Digital Marshall Testing Machine | Digital Marshall Testing Machine |
| Model | 1614021 | 1614022 |
| Supply power | 120 V, 60 Hz, 1ph | 220 V, 50 Hz, 1ph |
| Capacity | 50 kN | 50 kN |
| Resolution | 20 N | 20 N |
| Indicator | 4″ Touch Screen, Full Color | 4″ Touch Screen, Full Color |
| LoadRate | 50mm/min(2in/min) | 50mm/min(2in/min) |
| Displacement(Flowmeter) | 10×0.01mm dial gauge | 10×0.01mm dial gauge |
| Reporting Software | _ | _ |
| Dimension | 650x470x1060mm | 650x470x1060mm |
| Weight | 96kg | 96kg |
| Discription | Digital Marshall Testing Machine |
|---|---|
| Model | 1614021, 120 V, 50 kN, 1614022, 220 V, 50 kN |
| Supply power | 120V, 60Hz, 1ph, 220V, 50Hz, 1ph |
| Capacity | 50kN |
| Resolution | 20N |
| Indicator | 4" Touch Screen, Full Color |
| LoadRate | 50mm/min(2in/min) |
| Displacement(Flowmeter) | 10×0.01mm dial gauge |
| Reporting Software | _ |
| Dimension | 650x470x1060mm |
| Weight | 96kg |
